GENERAL INFORMATION

AutoMic-i600 is automated system for rapid and accurate biochemical identification of microorganisms and antimicrobial susceptibility testing (AST) with determination of MIC (Minimum Inhibitory Concentrations).

KEY FEATURES

• Rapid bacterial identification based on biochemical testing and comparison with an extensive database
• The identification system uses a dynamic continuous-monitoring method, allowing identification times to be reduced to 3 - 20 hours
• Automated antimicrobial susceptibility testing (AST) with sample inoculation, incubation, and result reading based on the broth microdilution method, compliant with the latest EUCAST standards
• Precise and reliable quantitative determination of MIC through real-time monitoring of microbial growth, ensuring accurate and reproducible results
• Automatic correction of antimicrobial susceptibility interpretation for intrinsic and acquired resistance, including ESBL-producing organisms, CRE, MRSA, VRE, PRSP, high-level aminoglycoside resistance (HLAR), and inducible clindamycin resistance, in accordance with EUCAST expert interpretation rules
• Two detection methods - colorimetric and turbidimetric - for maximum accuracy
• Intelligent AI-based algorithm that enhances result reliability
• Capacity of up to 64 samples simultaneously, suitable for laboratories with varying workloads
• Fully automated workflow, including inoculation, incubation, and result reading
• Direct export to WHONET for easy reporting and data analysis

TECHNICAL SPECIFICATIONS

• Capacity: 64 samples
• Injection method: automated sample addition
• Pipetting speed: <3 minutes / 120 samples
• Pipetting accuracy: 50 μl ± 3 μl / 100 μl ± 3 μl / 150 μl ± 3 μl
• Pipetting repeatability: 50 μl, 100 μl, 150 μl, CV ≤ 3%
• Incubation zone temperature: 35℃ ± 1.5℃
• Monitoring frequency: every 30 minutes
• Wavelength range: 400 nm ~ 700 nm
• Light source: LED
• Number of filters: up to 6

AVAILABLE TEST CARDS:

Antibiotic Susceptibility Panels

1. Gram-positive - including 20 antibiotics

• Range of application - Staphylococcus, Enterococcus, Bacillus

2. Enterobacteriaceae - including 26 antibiotics

• Range of application - Enterobacteria

3. Non-fermenting - including 22 antibiotics

• Range of application - Pseudomonas, Acinetobacter, Burkholderia cepacian, Stenotrophomonas maltophilia

4. Streptococcus - including 19 antibiotics

• Range of application - Streptococcus

5. Fungus - including 10 antibiotics

• Range of application - Candida, Cryptococcus and Aspergillus

Combined identification and antimicrobial susceptibility testing cards

1.Gram-positive - including 19 antibiotics

• Range of application - Corynebacterium, Bacillus, Listeria, Staphylococcus, Streptococcus, Enterococcus, Micrococcu etc.

2. Gram-negative - including 20 antibiotics

• Range of application - Salmonella, Shigella, Escherichia, Pantoea, Morganella, Yersinia, Pseudomonas, Acinetobacter, Moraxella, Bordetella, Vibrio, Aeromonas, Pasteur bacteria, etc.

3. Yeast - including 9 antibiotics

• Range of application - Yeast type fungal

Identification cards

1. Gram-positive

• Range of application - Corynebacterium, Bacillus, Listeria, Staphylococcus, Streptococcus, Enterococcus, Micrococcu etc.

2. Gram-negative

• Range of application - Salmonella, Shigella, Escherichia, Pantoea, Morganella, Yersinia, Pseudomonas, Acinetobacter, Moraxella, Bordetella, Vibrio, Aeromonas, Pasteur bacteria, etc.

3. Neisseria and Haemophilus - Coming soon

• Range of application - Neisseria и Haemophilus

Detection of resistance phenotypes:

• MRSA: Methicillin-resistant Staphylococcus aureus
• D test: Erythromycin induces Clindamycin resistance
• VISA：Vancomycin-mediated Staphylococcus aureus
• VRSA: Vancomycin-resistant Staphylococcus aureus
• VRE： Vancomycin-resistant Enterococcus
• PRSP: Penicillin-resistant Streptococcus pneumoniae
• HLAR: High-level aminoglycoside-resistant Enterococci
• ESBL: Extended-spectrum β-lactamase producing bacteria
• CRE：Carbapenem-resistant Enterobacteriaceae
